MATERIAL HANDLING
CHAIN CONVEYORS
At Go Fast Manufacturing, we offer a wide range of chain conveyors designed to meet your material handling needs. Whether you're transferring boards, cants, railroad ties, or full bundles of material, our chain rail conveyors can be configured to handle the job efficiently.
Built for durability and dependable performance, our systems feature customizable options to suit a variety of applications. With a focus on reliability and efficiency, Go Fast Manufacturing chain conveyors help streamline material flow and improve productivity throughout your operation.
machine details
Green Chain
Rooftop Transfer Chain
Inclined Cogged Chain
Our chain conveyors can be customized to meet the exact demands of your application, including size, chain type, and drive configuration. Contact Go Fast Manufacturing to discuss a solution built for your operation.
5" – 50"
0" – 3" (Standard Range)
1" – 2-1/2" (Standard Range)
30" – 72" Standard
Optional: 96", 120", 144"
3" – 4" (Standard Range)
Custom Data Collection Reports
Accessible via HMI or Email
Interfaces with Go Fast Machinery
Supports Custom Add-On E-Stops, Buttons & Sensors
Remote Access for Go Fast Engineering
Advanced Off-Site Diagnostics
Live Troubleshooting Screen in HMI
Displays Faults & Sensor States
Quick Diagnostic Access.
Board Counts
Machine Hours
Production Reports
3,000–7,000 Chain Lug Cycles Per Hour
Rotating Board Kick-Off Fingers
Catch Hooks for Doubled Boards
Thickness Limiter Bar
Seamless Conveyor Surface
Flat-Top Design Minimizes Angular Transitions
5-Strand 2060 Infeed
Evenly Spaced Cogs
UHMW Wear Strips
See-Through Guarding
Quick-Access Doors
Optional E-Stop Door Interlock
2HP Electric Motor
Welded Steel Frame
3/8" Thick Steel Plate Pit
3x2 Structural Steel Framing
1/4" Thick Steel Side Plates
Allows Notcher to Be Bypassed
Integrated with Overhead Conveyor
UpSTAK Stacker Integrated to Outfeed
Unscrambler Systems
Stringer Tilt Hoist Systems
Built to Accommodate Non-Standard Requirements
Modified for Unique Production Needs
1/3HP Electric Motor
Actuated Transition Plates
Toggle Switch to Air Cylinders
Dual 2060 Cogged Chain Strands
Seamless UHMW Transitions
Smooth Transfer to Board Stackers
